Ncaj Flutes End Mills

Spotlight Exhibits

Kev piav qhia

Hauv ntau qhov chaw ntawm kev tsim khoom thiab kev ua haujlwm, cov cuab yeej ua tau zoo thiab raug txiav yog tus yuam sij kom ntseeg tau cov khoom zoo thiab kev ua haujlwm zoo. No Ncaj Flutes End Mills yog cov cuab yeej txiav tsim los ua kom tau raws li koj cov kev xav tau ntau yam, uas yog tsim rau ntau yam lag luam xws li hlau ua, ntoo thiab yas. Lub milling cutter muaj ob lub npoo ncaj thiab yog ua los ntawm cov cemented carbide, thiab nws cov npoo txiav yog coated, uas tuaj yeem paub txog kev ua haujlwm zoo thiab raug ntawm cov khoom sib txawv. Qhov tseem ceeb tshaj, nws cov qauv yog compact heev, nws tsis yooj yim rau deform thaum lub sij hawm txiav, thiab nws muaj peev xwm tswj tau ruaj khov kev ua tau zoo.



Nta

1. Ob-ntug tsim: Ncaj Flutes End Mills muaj ob txoj kab ncaj nraim, uas ua rau lub cutter ruaj khov nyob rau hauv cov txheej txheem txiav thiab tuaj yeem paub txog kev ua haujlwm zoo. Qhov kev tsim no kuj ua rau cov cuab yeej txiav ntawm cov ces kaum sib txawv, uas tsim nyog rau ntau yam kev ua haujlwm machining.

2. Compact qauv: milling cutter muaj cov qauv compact, tuaj yeem ua haujlwm tau zoo hauv qhov chaw ua haujlwm tsawg, thiab tsim nyog rau ntau qhov chaw ua haujlwm.

3. Txheej kev kho mob: Nws cov ntug txiav yog coated ua kom nws ntse thiab tawv, uas tuaj yeem paub txog kev ua haujlwm siab ceev thiab txo cov cua sov thiab hnav.

4. Qhov ntau thiab tsawg thiab cov duab sib txawv: Nws muab ntau qhov ntau thiab tsawg thiab cov duab, suav nrog cov tes ntev thiab luv, kom ua tau raws li cov kev xav tau sib txawv.



Daim ntawv thov

• Hlau ua: Qhov Ncaj Flutes End Mills muaj kev ua tau zoo hauv kev ua haujlwm hlau. Nws ob-ntug tsim thiab txheej kev kho mob ua rau nws tsim nyog rau kev ua haujlwm zoo ntawm cov ntaub ntawv hlau xws li steel, aluminium thiab tooj liab.

• Woodworking: Hauv kev ua haujlwm ntawm woodworking, cov cuab yeej no muaj peev xwm sib npaug, uas tuaj yeem ua tiav qhov tseeb ntawm cov ntoo thiab muab cov kev daws teeb meem zoo rau cov rooj tog tsim khoom thiab cov khoom siv ntoo.

• Plastic processing: Nws txheej kev kho mob thiab cov qauv compact ua rau nws haum rau cov yas ua teb. Nws tuaj yeem paub txog cov yas txiav tau zoo thiab raug thiab muab kev txhawb nqa rau kev ua cov khoom yas.





Hoobkas





Product Description







SPECIFICATION	d1	L1	D	L
D3.175*17*D3.175*38L	3, 175 mm	17mm ib	3, 175 mm	38L
D3.175*22*D3.175*45L	3, 175 mm	22 hli	3, 175 mm	45L
D4*17*D4*50L	4mm ib	17mm ib	4mm ib	50L
D4*22*D4*50L	4mm ib	22 hli	4mm ib	50L
D6*22*D6*50L	6mm ib	22 hli	6mm ib	50L
D6*32*D6*60L	6mm ib	32mm ib	6mm ib	60L
D8*32*D8*60L	8mm ib	32mm ib	8mm ib	60L
D8*42*D8*75L	8mm ib	42mm ib	8mm ib	70L
D10*42*D10*75L	10 hli	42mm ib	10 hli	85L
D10*50*D10*100L	10 hli	62mm ib	10 hli	95L
D12*50*D12*100L	12 hli	50 hli	12 hli	100 hli
D14*50*D14*100L	14mm ib	50 hli	14mm ib	100 hli
D16*50*D16*100L	16 hli	50 hli	16 hli	100 hli
D20*50*D20*120L	20 hli	50 hli	20 hli	120 hli



Tolerances
Flute Diameter	Flute Diameter Tolerance	Shank Diameter kam rau ua
Φ1.0-Φ2.9	0~-0.02	H6
Φ3-Φ6	-0.01~-0.03
Φ6-Φ10	-0.01~-0.035
Φ10.0-Φ18.0	-0.01~-0.04
Φ18.0-Φ20.0	-0.015~-0.045



Daim ntawv thov
Multilayer Board	MDF	Ntoo Ntoo				EVE daim txhuam cev	Particleboard	Aluminium Alloy
		50 HRC	55 HRC	60 HRC	65 HRC
√	√	√	√				√



Raw Material List



Qib	ISO Code	Chemical Compositions (%)		Grain Size (um)	Physial Mechanical Properites (Ntau dua lossis sib npaug)			Txheej
		Wc	Co		Qhov ceev (g / cm3)	Hardness (HRA)	TRS (N / hli 2)
YG10X (50HRC)	K30-K40	89	10	0.8	14.43	91.5	2500	TSI
UF12U (55HRC)	K40	87	12	0.6	14.15	92.3	3900	TSI
AF501 (60HRC)	K05-K10	89	10	0.4	14.1	92.8	3600	NANO BLACK
AF308 (65 HRC)	K05-K10	91	8	0.3	14	93.8	3800	NANO (xim xiav)



Cov duab ntxaws





2 flute ncaj milling cutter	Cemented Carbide 2flute ncaj kawg Mill	2 flute ncaj endmill



Peb Qhov Zoo



1. Ntau tus kws tshaj lij, zoo dua thiab nrawm dua

2. Peb muaj cov kws tshaj lij cov ntaub ntawv tshawb fawb thiab kev tshawb fawb pab neeg rau ntau tshaj 15 xyoo, nrog rau ntau lub hauv ntej-kawg R&D, ntau lawm thiab tom qab-muag engineers, leej twg tuaj yeem teb cov lus nug kev 24 teev hauv ib hnub, pom zoo thiab hloov cov hniav qub rau koj, thiab txuag nqi.

3. Muab cov kev pabcuam thiab cov kev pabcuam rau koj. Cov cuab yeej uas tsis yog tus qauv tuaj yeem hloov kho rau koj, nrog rau 10- hnub xa khoom.

4. Tag nrho cov khoom ntawm cov txheej txheem txiav cov cuab yeej rau kev xa khoom sai.





Ntim





FAQ



1) Thaum twg kuv tuaj yeem tau txais tus nqi?

Peb feem ntau hais tsis pub dhau 24 teev tom qab peb tau txais koj qhov kev nug.Yog tias koj ceev heev kom tau txais tus nqi, thov hu rau peb los yog qhia rau peb hauv koj tus email kom peb yuav suav txog koj qhov kev nug tseem ceeb.



2) Kuv tuaj yeem tau txais cov qauv li cas los kuaj koj qhov zoo?

Tom qab kev lees paub tus nqi, koj tuaj yeem xav tau cov qauv los kuaj xyuas peb qhov zoo. Yog tias koj tsuas yog xav tau ib qho qauv dawb los kuaj xyuas tus qauv tsim thiab ntawv zoo, peb yuav muab cov qauv dawb rau koj, tsuav yog koj them tus nqi thauj khoom.



3) Kuv tuaj yeem cia siab tias yuav tau txais tus qauv ntev npaum li cas?

Tom qab koj them tus nqi coj mus kuaj thiab xa peb cov ntaub ntawv lees paub, cov qauv yuav npaj xa tuaj hauv 3-7 hnub. Cov qauv yuav raug xa tuaj rau koj ntawm kev nthuav qhia thiab tuaj txog hauv 3-5 hnub ua haujlwm. Koj tuaj yeem siv koj tus kheej tus account los yog them ua ntej yog tias koj tsis muaj tus account.



4) Ntev npaum li cas tag nrho cov txheej txheem tau ua tiav?

Tom qab koj tso qhov kev txiav txim, lub sij hawm tuav ntau lawm yog li ntawm 45-60 hnub. Peb xav tau 15 hnub los npaj tag nrho cov khoom ces 30 hnub rau kev tsim khoom.



5) Yuav ua li cas txog hnub thauj thiab xa khoom?

Feem ntau peb siv cov khoom xa tuaj rau transprot cov khoom.Nws yog li ntawm 25-40 hnub.Nws kuj tseem nyob ntawm qhov chaw coutry thiab chaw nres nkoj koj nyob.Nws yuav luv dua yog tias koj xav tau xa cov khoom xws li Neeg Esxias. Yog tias muaj qee qhov xwm txheej peb tuaj yeem xa cov khoom ntawm huab cua nthuav qhia, tsuav yog koj them cov nqi tsheb thauj mus los.
